DataLogic Matrix 220 Fixed Industrial Barcode Scanner
- Ultra-compact dimensions and rotating connectors for easy integration and installation in tight spaces
- Industrial grade electronic focus on all models for extreme reading flexibility
- New All-In-One DPM illuminator. Red and blue-light polarizing filter and diffused illuminator on one model for many applications needs and strong DPM reading performances
- Ultraviolet illumination system perfectly suitable for all the industrial applications characterized by UV-sensitive fluorescent ink
- Top performing High Power Illuminators models for challenging high speed applications
- New multicore image processing platform, excellent for high speed applications and capable of reading up to 2 mils code resolution
- Hardware Acceleration to speed up algorithms and improve decoding capabilities
- Digimarc Barcode reading technology for added value decoding applications
- High Dynamic Range to improve image quality and contrast
- Power over Ethernet option, onboard PROFINET IO and ETHERNET/IP for industrial connectivity
- OPC UA protocol for Industry 4.0
- Extreme industrial grade IP65 and IP67 ratings for harsh environments, -10 to 50 ºC/14 to 122 ºF operating temperature, new flexible cables suitable for robotic arms applications
- ESD and Anti-YAG protection as front cover accessory for extreme flexibility and optimized stock
Dispatch Details
– Ready to Dispatch in 1-7 Business Days
– Standard Shipping
– EMI Facility Available
Call for Price 99148 06616
The Datalogic Matrix 220 imager is the most compact image-based bar code reader, bringing you top performance with great flexibility. The lighting solutions on the Matrix 220 make it perfect for reading bar codes marked with DPM (direct part marking). An innovative scanner that was designed for superior performance, the Matrix 220 features a 1.2 MPixel high resolution sensor and a new multicore image processing platform. This scanner is especially great for applications that are used in warehouse and manufacturing.
- Dimensions: 78mm x 47mm x 38mm (3.07 x 1.85 x 1.50 in)
- Weight: 173 gr (6.1 oz)
- Operating Temperature: -10 to 50 °C / 14 to 122 °F
- Protection Class: IP65, IP67
- Sensor: 1.2 MPixel (1280 x 960), 45 frames/s
- Connectivity: Power over Ethernet, PROFINET, Ethernet/IP
- Reading Range: Minimum 40 mm, Maximum 600 mm (depending on model)
